Engineering Drawing by M. B. Shah, B. C. Rana

19.00 USD

Description engineering drawing, 2e continues to cover all thefundamental topics of the field, while maintaining its unique focuson the logic behind each concept and method. Based on extensivemarket research and reviews of the first edition, this editionincludes a new chapter on scales, the latest version of autocad,and new pedagogy. The coverage of topics has been made more clearand concise through over 300 solved examples and exercises, withnew problems added to help students work progressively throughthem. Combining technical accuracy with readable explanations, thisbook will be invaluable to both first-year undergraduateengineering students as well as those preparing for professionalexams. Learning goals through objectives overview of the chapter through introduction recap of concepts through solved examples application of concepts through exercises real-world applications through critical thinking exercises basics of engineering drawing symbolic lines and lettering geometrical constructions, loci and engineering plane curves scales projections of points and lines projections on auxiliary reference planes projections of planes projections of solids sections of solids intersection of surfaces development of surfaces multiview orthographic projections sectional views dimensioning auxiliary views reading orthographic projections isometric projections oblique parallel projections and perspective projections threaded fasteners riveted and welded joints computer-aided drafting m. B. Shah is a professor of mechanical engineering and theprincipal of shah and anchor kutchhi engineering college, mumbai. B. C. Rana was an assistant professor at veermata jijabaitechnological institute.

---
